          3600 RPM Motors

          Key Characteristics vs other rotary electric vibrators: Highest RPM, best for silos, hoppers and small to mid-sized containers.

          General Characteristics: Rugged, energy efficient, low noise, and low maintenance.

          Energy Source: Electric.

          Force Output: Radial.

          Force Output Range: 114 to 19,000 lbs.

          Usage Recommendation: Continuous operations at 100% force when considering energy usage and life.

          Description: A rotating motor with oversized shaft, bearings and eccentric weights on the shaft generates centrifugal force. 3600 RPM is constant on most models. Force output is adjusted by changing the unbalance of the weights.

          Product Applications: Material flow for silos and small to mid-size containers.


          All Rotary Electric Vibrators must be used with an on/off motor control with overload protection and proper mounting per operator manual instructions.

          • 115V vibrators usually include On/Off Control Box bundles with purchase of vibrator.
          • 230V and 460V vibrators do not include control box options as a bundle, however special control boxes can be ordered seperately.





          * Click on the model number below to view accessories specific to that model *

          Category Sort Order
          Model Price
          Part #: 600385C
          Max Force: 1036
          Manufacturer: Italvibras
          $1737.00 Quantity:
          Part #: 600385$
          Max Force: 1036
          Manufacturer: Italvibras
          $1781.00 Quantity:
          Part #: 600387C
          Max Force: 1659
          Manufacturer: Italvibras
          $1992.00 Quantity:
          Part #: 600387$
          Max Force: 1659
          Manufacturer: Italvibras
          $2184.00 Quantity:
          Part #: 600389C
          Max Force: 2334
          Manufacturer: Italvibras
          $2565.00 Quantity:
          Part #: 600437C
          Max Force: 3524
          Manufacturer: Italvibras
          $3693.00 Quantity:
          Part #: 600317C
          Max Force: 4576
          Manufacturer: Italvibras
          $3791.00 Quantity:
          Part #: 600384C
          Max Force: 653
          Manufacturer: Italvibras
          $1586.00 Quantity:
          Part #: 600384$
          Max Force: 653
          Manufacturer: Italvibras
          $1598.00 Quantity:
          Part #: 600314C
          Max Force: 1036
          Manufacturer: Italvibras
          $705.00 Quantity:
          Part #: 600314$
          Max Force: 1036
          Manufacturer: Italvibras
          $1253.00 Quantity:
          Part #: 600366C
          Max Force: 1515
          Manufacturer: Italvibras
          $864.00 Quantity:
          Part #: 600381C
          Max Force: 1659
          Manufacturer: Italvibras
          $979.00 Quantity:
          Part #: 600381$
          Max Force: 1659
          Manufacturer: Italvibras
          $1787.00 Quantity:
          Part #: 600513C
          Max Force: 2334
          Manufacturer: Italvibras
          $1609.00 Quantity:
          Part #: 600491C
          Max Force: 2919
          Manufacturer: Italvibras
          $1611.00 Quantity:
          Part #: 600502C
          Max Force: 3263
          Manufacturer: Italvibras
          $1976.00 Quantity:
          Part #: 600311C
          Max Force: 383
          Manufacturer: Italvibras
          $407.00 Quantity:
          Part #: 600311$
          Max Force: 383
          Manufacturer: Italvibras
          $832.00 Quantity:
          Part #: 600256C
          Max Force: 4077
          Manufacturer: Italvibras
          $2287.00 Quantity:
          Part #: 600312C
          Max Force: 480
          Manufacturer: Italvibras
          $457.00 Quantity:
          Part #: 600312$
          Max Force: 480
          Manufacturer: Italvibras
          $879.00 Quantity:
          Part #: 600257C
          Max Force: 4893
          Manufacturer: Italvibras
          $2325.00 Quantity:
          Part #: 600313C
          Max Force: 653
          Manufacturer: Italvibras
          $597.00 Quantity:
          Part #: 600313$
          Max Force: 653
          Manufacturer: Italvibras
          $1033.00 Quantity:

          102 product(s) found.
